Laboratory fridge-freezer with NoFrost, Right Hinged - SCFVH4032PERFECTION
Color : Other
Key Features
+2 °C SafetyDevice
NoFrost technology
Easy to clean interior
Alarm relay
German engineering
Ultra efficient
Available from Drimmers Appliances, serving customers throughout Florida.
Features
+2 °C SafetyDevice
If the temperature falls below +2 °C due to a malfunction while the temperature setting is at +5 °C or higher, the SafetyDevice takes control, stabilizing the temperature, activating the alarm and protecting the contents from freezing. At colder settings, this activation threshold decreases relatively with the temperature setting.
NoFrost technology
With professional laboratory appliances from Liebherr, defrosting is no longer necessary. Any moisture that occurs is bound by the fan-assisted cooling, and needs-based defrosting phases drive even the last moisture particles out of the interior. For convenient, safe, and ice-free storage.
Easy to clean interior
The plastic inside container is made of polystyrene: a fully recyclable, robust, and odorless plastic. Manufactured seamlessly from one piece, it has no hidden dirt traps and the large corners can be cleaned quickly and easily. The perfect combination of sustainability and hygiene.
Alarm relay
In the event of an alarm, the responsible control center is informed immediately, usually through connection to the building control system. You can define in advance which alarms are to be forwarded, as well as set how long the forwarding remains active and whether a reminder should be sent after the alarm acknowledgement. This allows you to react immediately in critical situations.
German engineering
Our superior products offer premium quality, cutting edge design and innovative features that fit with your busy lifestyle. Plus, exclusive components and materials along with the latest production processes ensure energy efficiency and performance for years to come.
Ultra efficient
Energy-efficient refrigerators and freezers help with ever increasing electricity prices. Liebherr fully utilizes the savings potential of every component – from the compressor to the seal, to the lighting and electronics. The ultra-efficient appliances in the Perfection series, for example, demonstrate how this has a positive effect on your overall operating costs.
Specifications
Other
| Cleanroom class according to ISO EN 14664-1 | ISO class 5 |
| Total gross volume | 13.7 |
| Load-bearing capacity of shelf areas, refrigerator compartment | 99.2 |
| Total net volume | 11.4 |
| Certifications | Labgrade Energy Star / UL 61010-2-011 |
| Load-bearing capacity of shelf areas, freezer compartment | 88.2 |
Dimensions & Weight
| Width | 23.56 in. |
| Height | 80.5 in. |
| Length | 25.75 in. |
| Weight | 220.5 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 28.56 in. |
| Shipping Height | 85.5 in. |
| Shipping Length | 30.75 in. |
| Shipping Weight | 260.5 lbs. |
| Total of Shipping Weight | 260.5 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 28.27 ft³ |
| Dimensional Weight | 351.38 lbs. |
| Total of Cubes | 28.27 ft³ |
| Total of Dimensional Weight | 351.38 lbs. |
Exterior dimensions: height/width/depth
| Exterior dimensions: height/width/depth | 80 1/2 | 23 1/2 | 25 3/4 inch |
Adjustable temperature range
| Adjustable temperature range | -9 °C to -30 °C |
General product information
| Model type | Laboratory fridge-freezer with NoFrost |
| Classification | Perfection |
| GTIN | 9005382247792 |
Output and consumption
| Refrigerant | R 600a |
| Heat distribution system | Air cooling |
| Voltage | 115-127 V ~ |
| Frequency | 60 Hz |
| Energy consumption in 24h | 1.300 kWh / 24h |
| Measurement methodology for energy consumption | Empty measurement +41 °F / –4 °F / ambient temperature +77 °F |
| Noise level | 48 dB |
| Energy consumption per year | 475 kWh/a |
| Ambient temperature | 50°F to 95°F |
| Heat emission | 380 kJ / h |
| Rated power consumption Watt | 160.0 W |
Control and functions
| Data logger | integrated, USB interface |
| Control unit | Touch & Swipe |
| Power failure alarm | immediately upon power failure for min. 12h |
| Connectivity type | SmartModule |
| potential-free contact | ✔ |
| Interface | WLAN/LAN |
| Malfunction: Warning signal | optical and acoustical |
| Alarm history | Yes |
| min./max. temperature recording | Yes |
| Product sensor | integrated |
| positive temperature deviation from the setpoint | 1.6 Kelvin |
| negative temperature deviation from the setpoint | 1.8 Kelvin |
| Heating from +5 °C to +10 °C (empty, +25 °C TU) | 50 min |
| Heating from -20°C to -15°C (empty, +25°C TU) | 55 min |
| Cooling time from +25°C to +5°C (empty, +25°C TU) | 30 min |
| Cooling time from +25 °C to -20 °C (empty, +25 °C TU) | 180 min |
| Recovery time after 1 min door opening (empty, +25 °C TU, according to EN 60068-3) | 10 min |
Refrigerator compartment
| Bottom grid shelf | — |
| Temperature display | external digital |
| Adjustable temperature range | +3 °C to +16 °C |
| Defrosting method | automatic |
| Number of storage shelves | 5 |
| of which adjustable | 4 |
| Interior light | LED lighting column, left |
Freezer compartment
| Drawers in freezer compartment | 3 |
| Adjustable temperature range | -9 °C to -30 °C |
| Bottom grid shelf | — |
| Number of storage shelves | 3 |
| Cooling technology | NoFrost |
| of which adjustable | 0 |
| Defrosting method | automatic |
| Interior light | LED lighting |
Design and materials
| Material of adjustable feet | Steel, zinced |
| Side wall material | steel |
| Handle | Antimicrobial handle with opening mechanism |
| Material of interior containers | Plastic white |
| Material of adjustable shelves in the freezer compartment | Glass |
| Cabinet Material | white |
| Cabinet Material | Insulated glass door, steel |
| Storage shelf material, fridge compartment | Plastic-coated grids |
Set-up and installation
| Door seal | Replaceable |
| Self-closing door | ✔ |
| Door hinge replacement | Possible for customer |
| Door hinges | Right |
| Castors | — |
| Type of castors | — |
| Height-adjustable feet | — mm |
| Lock | without remote control |
| Max. height of the installation site | 4,900 ft above sea level |
| Connector cable (length) | 3,000 mm |
Specifications
| Certifications | Labgrade Energy Star / UL 61010-2-011 |
| Total gross volume | 13.7 cubic feet |
| Total net volume | 11.4 cubic feet |
| Exterior dimensions: height/width/depth | 80 1/2 | 23 1/2 | 25 3/4 inch |
| Weight (with packaging) | 231.30 pounds |
| Exterior dimensions: height/width/depth (with packaging) | 2,080.0 / 615.0 / 725.0 mm |
| Weight (without packaging) | 220.00 pounds |
| Load-bearing capacity of shelf areas, refrigerator compartment | 99.2 pounds |
| Load-bearing capacity of shelf areas, freezer compartment | 88.2 pounds |
| Measurements: net depth of storage shelves in inches | 16 11/16 inch |
| Clean room class according to ISO EN 14664-1 | ISO class 5 |
