$2,599.00
$2,599.00
Rebate AvailableColor : Stainless steel
$2,599.00
Current Rebates
Key Features
Knob controls
LED ClearView lighting
Temperature sensor
Miele CleanCover
Available from Drimmers Appliances, serving customers throughout Florida.
Features
Knob controls
Beautiful and functional: Metal rotary controls complement the harmonious design of the range hoods.
LED ClearView lighting
Eco-friendly and very durable: With up to 4 x 2 W, they provide the cooktop with uniform, warm downlighting.
Temperature sensor
Continuous monitoring: the temperature sensor ensures safety and prevents unnecessary energy consumption.
Miele CleanCover
Miele’s unique easy cleaning: The sealed, smooth surface prevents contact with the electrical components/motor.
Specifications
Operating modes
| Recirculated mode | Can be retrofitted |
| External operation possible | Yes |
Design
| Wall ventilation hood | Yes |
Required accessories
| Blower | Yes |
| Duct cover | Yes |
User convenience
| Rotary knob | Yes |
| Power levels (number excl. Intensive) | 3 |
| Temperature sensor | Yes |
Cleaning convenience
| Easy to clean canopy interior CleanCover | Yes |
| Dishwasher-safe grease collection channel | Yes |
Filter system
| Number of dishwasher-safe stainless steel baffle filters | 2 |
Lighting
| LED | Yes |
| Number x W | 2 x 3 W |
Fan option (buy separately)
| DRIB XL internal blower in CFM (m³(h) | 1189 |
| DREB XL external blower in CFM (m³/h) | 1189 |
Installation note
| Vent connection at top | Yes |
| Diameter of vent connection in in.(mm) | 9 7/8 (250) |
Standard accessories
| Non-return flap | Yes |
Other
| Standard plug fitted | Yes |
| Total connected load in kW | 0.81 |
| Voltage in V | 120 |
| Fuse rating in A | 15 |
| Number of phases | 1 |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 34.88 in. |
| Shipping Height | 23 in. |
| Shipping Length | 29 in. |
| Shipping Weight | 100 lbs. |
| Total of Shipping Weight | 100 lbs. |
| Source | Calculation |
Dimensions & Weight
| Gross Weight | 90.39 lbs. |
| Width | 29.88 in. |
| Height | 18 in. |
| Weight | 60 lbs. |
| Depth | 24 in. |
Technical data
| Length of electrical wire in ft (m) | 2 (0.8) |
| Standard plug fitted | Yes |
| Voltage in V | 120 |
| Fuse rating in A | 15 |
| Number of phases | 1 |
| Total connected load in kW | 0.806 |
| Plug type | NEMA plug: 5–15 |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 7.47 ft³ |
| Dimensional Weight | 92.86 lbs. |
| Total of Cubes | 7.47 ft³ |
| Total of Dimensional Weight | 92.86 lbs. |
General information
| Model number | DAR 1220-3 |
| Manufacturer material number | 11898130 |
| EAN number | 4002516546931 |
| Marketing class | Gold |
